DEGONG-1/4"-4"
DEGONG
| Technical specifications |
| Material | Brass |
Size | 1/4" -4" (DN6-DN100) |
| pressure | 1000psi |
Temperature range | -20-180 degree C |
connection | Butt weld,Threaded |
sealing | PTFE,RPTFE,PPL ETC |
Production process | Investment casting, CNC lathe, Test, Cleaning, Packing, Storage |
Main products | Includes ball valve, butterfly valve, check valve, gate valve, strainer, etc. |
| Application | Suitable for fire piping system, air, steam, water,gas, oil , home decoration , equipment and so on |
| Package | Buyer's drawing or designs are available |
| Cartons without pallet | |
| Cartons with pallet | |
| Double woven bags | |
| Or as buyer's requirements |
| Features |
It is suitable for frequent operation, opening and closing quickly and lightly.
The fluid resistance is small.
Simple structure, relatively small size, light weight and easy maintenance.
Good sealing performance.
It is not restricted by the installation direction, and the flow direction of the medium can be arbitrary.
| Product parameter |
| DN | NPS | G | Φd | L | W |
| 15 | 1/2'' | 1/2 | 15 | 75 | 100 |
| 20 | 3/4'' | 3/4 | 20 | 80 | 120 |
| 25 | 1'' | 1 | 25 | 90 | 140 |
| 32 | 1 1/4'' | 1 1/4 | 32 | 110 | 140 |
| 40 | 1 1/2'' | 1 1/2 | 38 | 120 | 180 |
| 50 | 2'' | 2 | 50 | 140 | 200 |
| 65 | 2 1/2'' | 2 1/2 | 64 | 160 | 220 |
| 80 | 3'' | 3 | 78 | 180 | 240 |
| 100 | 4'' | 4 | 100 | 215 | 300 |
| Contact us |
We can customize product specifications according to your requirements. If you have any needs or questions, please contact us.
